Main GMPE Functions Guide

library(GMPEhaz)

Introduction

The GMPEhaz package provides multiple Ground Motion Prediction Equations (GMPEs) covering prediction models for both crustal and subduction zone earthquakes. This document introduces the most important GMPE functions in the package, including internationally recognized NGA-West2 models and Taiwan-specific models.

Crustal Earthquake GMPE Models

1. BSSA14 - Boore et al. (2014) NGA-West2

BSSA14 is one of the important models in the NGA-West2 project, suitable for ground motion prediction of shallow crustal earthquakes.

# BSSA14 function parameter description
# Mag: Earthquake magnitude
# Rjb: Joyner-Boore distance (km)
# Prd: Period (0 for PGA, -1 for PGV)
# Vs30: 30-meter average shear wave velocity (m/s)
# ftype: Fault type (0=strike-slip, 1=reverse, -1=normal)
# Z1.0: Depth to 1.0 km/s shear wave velocity (km)
# regionflag: Region flag (0=global, 1=China-Turkey, 2=Italy-Japan)
# basinflag: Basin adjustment

# Example: Magnitude 6 earthquake, 20km distance, rock site
result_bssa14 <- BSSA14(Mag=6, Rjb=20, Prd=0, Vs30=760, ftype=0, Z1.0=0.5, regionflag=0, basinflag=0)
cat("BSSA14 PGA prediction results:\n")
#> BSSA14 PGA prediction results:
cat("Log value:", round(result_bssa14$lnY, 3), "\n")
#> Log value: 4.578
cat("PGA(g):", round(exp(result_bssa14$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.099
cat("Standard deviation:", round(result_bssa14$sigma, 3), "\n")
#> Standard deviation: 0.605

2. CY14 - Chiou and Youngs (2014) NGA-West2

CY14 model considers more parameters, including complex factors such as hanging wall effects.

# CY14 requires more parameters
# Rrup: Rupture distance (km)
# Dip: Fault dip angle (degrees)
# Ztor: Depth to top of rupture (km)
# Vs30_class: Vs30 classification (1=measured, 0=estimated)
# hwflag: Hanging wall flag (1=hanging wall, 0=not hanging wall)
# Rx: Horizontal distance perpendicular to fault strike (km)

result_cy14 <- CY14(Mag=6, Rrup=20, Rjb=20, Prd=0, ftype=0, Vs30=760,
                    Dip=90, Ztor=0, Z1.0=0.5, Vs30_class=1, hwflag=0, Rx=20, regionflag=0)
cat("CY14 PGA prediction results:\n")
#> CY14 PGA prediction results:
cat("Log value:", round(result_cy14$lnY, 3), "\n")
#> Log value: 4.268
cat("PGA(g):", round(exp(result_cy14$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.073

3. ASB14 - Akkar et al. (2014)

ASB14 is a crustal earthquake model developed for European and Middle Eastern regions.

# ASB14 is relatively simple, main parameters include magnitude, distance, fault type and site conditions
result_asb14 <- ASB14(Mag=6, Rjb=20, Prd=0, ftype=0, Vs30=760)
cat("ASB14 PGA prediction results:\n")
#> ASB14 PGA prediction results:
cat("Log value:", round(result_asb14$lnY, 3), "\n")
#> Log value: 4.2
cat("PGA(g):", round(exp(result_asb14$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.068

4. BI14 - Bindi et al. (2014)

BI14 is a pan-European ground motion prediction equation developed based on the RESORCE database.

result_bi14 <- BI14(Mag=6, Rjb=20, Prd=0, ftype=0, Vs30=760)
cat("BI14 PGA prediction results:\n")
#> BI14 PGA prediction results:
cat("Log value:", round(result_bi14$lnY, 3), "\n")
#> Log value: 4.14
cat("PGA(g):", round(exp(result_bi14$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.064

Taiwan-Specific Models

5. Lin11 - Lin et al. (2011)

Lin11 is a model specifically developed for Taiwan shallow crustal earthquakes, considering Taiwan’s special geological conditions.

# Lin11 model distinguishes between rock and soil sites (based on Vs30)
# hwflag: Hanging wall effect flag

result_lin11 <- Lin11(Mag=6, Rrup=20, Prd=0, hwflag=0, Vs30=760)
cat("Lin11 PGA prediction results:\n")
#> Lin11 PGA prediction results:
cat("Log value:", round(result_lin11$lnY, 3), "\n")
#> Log value: 4.37
cat("PGA(g):", round(exp(result_lin11$lnY/exp(6.89)), 3), "\n")
#> PGA(g): 1.004

Subduction Zone Earthquake Models

6. LL08 - Lin and Lee (2008)

LL08 is a model specifically developed for subduction zone earthquakes in northeastern Taiwan.

# LL08 is applicable to subduction zone earthquakes
# ftype: 0=interface earthquake, 1=intraslab earthquake
# depth: Source depth (km)

result_ll08 <- LL08(Mag=6, Rrup=20, depth=10, ftype=0, Prd=0, Vs30=760)
cat("LL08 PGA prediction results:\n")
#> LL08 PGA prediction results:
cat("Log value:", round(result_ll08$lnY, 3), "\n")
#> Log value: 4.533
cat("PGA(g):", round(exp(result_ll08$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.095

7. BCHydroSub2018Global - Abrahamson et al. (2018)

BCHydroSub2018Global is a modern model developed for global subduction zone earthquakes.

# BCHydroSub2018Global considers forearc/backarc effects
# forearc: 0=forearc, 1=backarc
# Rhypo: Hypocentral distance (km)

result_bch <- BCHydroSub2018Global(Mag=6, Rrup=20, Prd=0, ftype=0, Vs30=760,
                                   forearc=1, depth=10, Rhypo=25)
cat("BCHydroSub2018Global PGA prediction results:\n")
#> BCHydroSub2018Global PGA prediction results:
cat("Log value:", round(result_bch$lnY, 3), "\n")
#> Log value: 4.586
cat("PGA(g):", round(exp(result_bch$lnY), 3)/exp(6.89), "\n")
#> PGA(g): 0.09985633

Multi-Period Analysis Example

All GMPE functions support response spectrum calculations for different periods:

# Calculate response spectrum for different periods
periods <- c(0, 0.1, 0.2, 0.5, 1.0, 2.0)  # Including PGA(0) and different periods
mag <- 7
distance <- 30
vs30 <- 760

# Calculate response spectrum using BSSA14
results <- data.frame(
  Period = periods,
  BSSA14_lnSa = numeric(length(periods)),
  CY14_lnSa = numeric(length(periods))
)

for(i in 1:length(periods)) {
  # BSSA14
  bssa_result <- BSSA14(Mag=mag, Rjb=distance, Prd=periods[i], Vs30=vs30,
                        ftype=0, Z1.0=0.5, regionflag=0, basinflag=0)
  results$BSSA14_lnSa[i] <- bssa_result$lnY

  # CY14
  cy_result <- CY14(Mag=mag, Rrup=distance, Rjb=distance, Prd=periods[i],
                    ftype=0, Vs30=vs30, Dip=90, Ztor=0, Z1.0=0.5,
                    Vs30_class=1, hwflag=0, Rx=distance, regionflag=0)
  results$CY14_lnSa[i] <- cy_result$lnY
}

print(results)
#>   Period BSSA14_lnSa CY14_lnSa
#> 1    0.0    4.654815  4.591543
#> 2    0.1    5.302432  5.370060
#> 3    0.2    5.467485  5.408326
#> 4    0.5    4.920472  4.853676
#> 5    1.0    4.216129  4.182009
#> 6    2.0    3.359481  3.456293

# Plot response spectrum comparison chart
plot(results$Period, exp(results$BSSA14_lnSa)/exp(6.89), type="l", col="blue", lwd=2,
     xlab="Period (sec)", ylab="Spectral Acceleration (g)",
     main="Response Spectrum Comparison (M7.0, R=30km)",
     ylim=c(0, max(exp(results$BSSA14_lnSa)/exp(6.89), exp(results$CY14_lnSa)/exp(6.89))))
lines(results$Period, exp(results$CY14_lnSa)/exp(6.89), col="red", lwd=2)
legend("topright", legend=c("BSSA14", "CY14"), col=c("blue", "red"), lwd=2)
grid()

Taiwan-Specific Recent Models

8. Chao2018 - Chao et al. (2018)

Chao2018 is a comprehensive GMPE model developed for both crustal and subduction earthquakes in Taiwan region.

# Chao2018 function parameter description
# Mag: Earthquake magnitude
# Rrup: Rupture distance (km)
# Prd: Period (0 for PGA)
# ftype: Fault mechanism (-1=normal, 0=strike-slip, 1=reverse for crustal; 0=interface, 1=intraslab for subduction)
# Vs30: 30-meter average shear wave velocity (m/s)
# Vs30_class: Vs30 data quality (0=estimated, 1=measured)
# Ztor: Depth to top of rupture (km)
# Z1.0: Depth to 1.0 km/s shear wave velocity (km)
# sourcetype: Source type (0=crustal, 1=subduction)
# msasflag: Mainshock/aftershock flag (0=mainshock, 1=aftershock)

# Example: Crustal earthquake
result_chao2018_crustal <- Chao2018(Mag=6.5, Rrup=30, Prd=0, ftype=0, Vs30=760,
                                   Vs30_class=1, Ztor=5, Z1.0=0.5, sourcetype=0, msasflag=0)
cat("Chao2018 Crustal PGA prediction:\n")
#> Chao2018 Crustal PGA prediction:
cat("Log value:", round(result_chao2018_crustal$lnY, 3), "\n")
#> Log value: 4.459
cat("PGA(g):", round(exp(result_chao2018_crustal$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.088

# Example: Subduction interface earthquake
result_chao2018_sub <- Chao2018(Mag=7.5, Rrup=50, Prd=0, ftype=0, Vs30=760,
                               Vs30_class=1, Ztor=0, Z1.0=0.5, sourcetype=1, msasflag=0)
cat("Chao2018 Subduction Interface PGA prediction:\n")
#> Chao2018 Subduction Interface PGA prediction:
cat("Log value:", round(result_chao2018_sub$lnY, 3), "\n")
#> Log value: 4.224
cat("PGA(g):", round(exp(result_chao2018_sub$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.069

9. PhungCru18 - Phung et al. (2018) Crustal

PhungCru18 is a crustal GMPE model developed specifically for Taiwan with regional adjustments.

# PhungCru18 function parameter description
# Mag: Earthquake magnitude
# Rrup: Rupture distance (km)
# Rjb: Joyner-Boore distance (km)
# Rx: Horizontal distance from top edge of rupture (km)
# Prd: Period (0 for PGA)
# Vs30: 30-meter average shear wave velocity (m/s)
# Dip: Dip angle of the fault plane (degrees)
# Ztor: Depth to top of rupture (km)
# ftype: Fault mechanism (-1=normal, 0=strike-slip, 1=reverse)
# Z1.0: Depth to 1.0 km/s shear wave velocity (km)
# Vs30_class: Vs30 data quality (0=estimated, 1=measured)
# regionflag: Regional flag (0=global, 1=Taiwan)
# hwflag: Hanging wall flag (0=footwall, 1=hanging wall)

# Example: Taiwan crustal earthquake
result_phungcru18 <- PhungCru18(Mag=6.5, Rrup=25, Rjb=20, Rx=15, Prd=0, Vs30=760,
                               Dip=90, Ztor=5, ftype=0, Z1.0=0.5, Vs30_class=1,
                               regionflag=1, hwflag=0)
cat("PhungCru18 Taiwan PGA prediction:\n")
#> PhungCru18 Taiwan PGA prediction:
cat("Log value:", round(result_phungcru18$lnY, 3), "\n")
#> Log value: 4.441
cat("PGA(g):", round(exp(result_phungcru18$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.086

10. PhungSub18 - Phung et al. (2018) Subduction

PhungSub18 is a subduction zone GMPE model developed for Taiwan and Japan regions.

# PhungSub18 function parameter description
# Mag: Earthquake magnitude
# Rrup: Rupture distance (km)
# Prd: Period (0 for PGA)
# ftype: Fault type (0=interface, 1=intraslab)
# Vs30: 30-meter average shear wave velocity (m/s)
# Z1.0: Depth to 1.0 km/s shear wave velocity (km)
# Ztor: Depth to top of rupture (km)
# regionflag: Regional flag (0=Japan, 1=Taiwan)

# Example: Taiwan interface earthquake
result_phungsub18_int <- PhungSub18(Mag=7.5, Rrup=50, Prd=0, ftype=0, Vs30=760,
                                   Z1.0=0.5, Ztor=0, regionflag=1)
cat("PhungSub18 Taiwan Interface PGA prediction:\n")
#> PhungSub18 Taiwan Interface PGA prediction:
cat("Log value:", round(result_phungsub18_int$lnY, 3), "\n")
#> Log value: 4.183
cat("PGA(g):", round(exp(result_phungsub18_int$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.067

# Example: Taiwan intraslab earthquake
result_phungsub18_slab <- PhungSub18(Mag=7.0, Rrup=60, Prd=0, ftype=1, Vs30=760,
                                    Z1.0=0.5, Ztor=30, regionflag=1)
cat("PhungSub18 Taiwan Intraslab PGA prediction:\n")
#> PhungSub18 Taiwan Intraslab PGA prediction:
cat("Log value:", round(result_phungsub18_slab$lnY, 3), "\n")
#> Log value: 4.281
cat("PGA(g):", round(exp(result_phungsub18_slab$lnY)/exp(6.89), 3), "\n")
#> PGA(g): 0.074

Model Selection Guide

Crustal Earthquakes

BSSA14, CY14: Suitable for global shallow crustal earthquakes, NGA-West2 series with rich datasets
ASB14, BI14: Suitable for European regions, considering European geological characteristics
Lin11: Specifically for Taiwan crustal earthquakes, considering Taiwan’s special geological conditions
Chao2018, PhungCru18: Latest Taiwan-specific models with local calibration

Subduction Zone Earthquakes

BCHydroSub2018Global: Modern global subduction model with wide applicability
LL08: Specifically for Taiwan’s northeastern subduction zone, considering Taiwan’s special subduction characteristics
Chao2018, PhungSub18: Recent Taiwan-specific subduction models

Parameter Importance

Magnitude (Mag): Most important parameter with the greatest impact on ground motion intensity
Distance: Rrup (rupture distance) is usually more accurate than Rjb (Joyner-Boore distance)
Site conditions (Vs30): Important impact on ground motion amplification effects
Fault type (ftype): Affects ground motion characteristics
Regional parameters: Consider geological differences in different regions

Conclusion

The GMPEhaz package provides a rich selection of GMPE models. Users can choose appropriate models based on study region, earthquake type, and available parameters. It is recommended to use multiple models for comparison and validation when conducting seismic hazard analysis to obtain more reliable results.

Person Lin

2026-03-31
